Adjusting Caster Camber?
#16
Registered User
The former you're basically stuck with, but caster changes as you rotate the axle housing, i.e. lift the pinion up and down.
#17
Administrator
Thanks for straightening me out on that, it has been many years since vocational mechanics school. So inclination means side to side angle and alters camber and the fore aft angle, or inclination is caster, I'm sooo confused ...Mark
#18
Registered User
Been a long time since automechanics class for me too. I've forced myself to keep a working knowledge of it as I do my own steering adjustments and modifications.
Offset bushings (or whatever they call them) for the kingpins can change camber or caster depending on how you clock them. I think we're talking less than a degree of correction here though.
What's important about the kingpin inclination is the angle exists even when the camber is zero. It dictates the scrub radius of the tire. Increase the scrub through negative wheel offset for better handling. A decrease in scrub (i.e. taller tire on stock wheel) tends to have more wander.
Offset bushings (or whatever they call them) for the kingpins can change camber or caster depending on how you clock them. I think we're talking less than a degree of correction here though.
What's important about the kingpin inclination is the angle exists even when the camber is zero. It dictates the scrub radius of the tire. Increase the scrub through negative wheel offset for better handling. A decrease in scrub (i.e. taller tire on stock wheel) tends to have more wander.
#19
Registered User
Thread Starter
Double the caster, or add say 5 degrees and report back. Factory spec is usually not enough on solid axle trucks. Caster will keep your truck going straight even with slack in the steering box.
EDIT: use degree shims under your leaf springs, or longer shackles to increase caster.
EDIT: use degree shims under your leaf springs, or longer shackles to increase caster.
And thank you, Maybe 368, and u2slow for your very informative replies
also would the shims go under the front or rear of the springs, and what would that do to the pinion angle?
#20
Registered User
It does make your front pinion angle slightly worse, and slightly more driveshaft angle. I can't imagine any consequences 0-2" lift.
I run 2" leafs, 1" zero-rate, and 5" shackles (stock is <4") and grinding some lumps off the CV. No binding.
I considered buying wedges, but decided I could make my own shackles instead.
I run 2" leafs, 1" zero-rate, and 5" shackles (stock is <4") and grinding some lumps off the CV. No binding.
I considered buying wedges, but decided I could make my own shackles instead.
#21
Registered User
I have the stock lift, Custom Suspension parabolic front springs on this, along with the pro comp 3000 hydraulic shocks all the way around. The time and money I've put into the front of this truck, well it should drive like a new truck, and for the most part it does.
But when going down the road you have to be on your toes constantly cuz out of the blue it will just quit tracking like it should, heading one way or the other, nothing violent just not normal behavior and it's driving me nuts lol. BTW its the 92 in my sig and my avatar, and my DD and it drove just like this with the stock tires on it.
But when going down the road you have to be on your toes constantly cuz out of the blue it will just quit tracking like it should, heading one way or the other, nothing violent just not normal behavior and it's driving me nuts lol. BTW its the 92 in my sig and my avatar, and my DD and it drove just like this with the stock tires on it.
This is EXACTLY what my '93 is doing. I have changed every replaceable part that could have even the slightest effect on handling and nothing has fixed it.
Let us know what you find, because it sounds like I need the exact same thing.
#22
Registered User
Thread Starter
1972 RedNeck, earlier in my post you said you ordered the bushings, did you get them installed? Did they not help?
Thanks
Vern
BTW, we are on 10+ hour shifts right now so it will probably be Sat before I have a chance to work on the truck
Thanks
Vern
BTW, we are on 10+ hour shifts right now so it will probably be Sat before I have a chance to work on the truck
#23
Registered User
Do some googling and read some Pirate4x4 threads on solid-axle caster... 5-10 degrees comes up time and time again.
Did you use the longer shackles that Carrier supplies with those springs? IIRC, they're somewhere between 1/2" and 1" longer than stock, and that's a caster increase.
Did you use the longer shackles that Carrier supplies with those springs? IIRC, they're somewhere between 1/2" and 1" longer than stock, and that's a caster increase.
The following users liked this post:
nonrev (06-08-2018)
#24
Registered User
Thread Starter
Did you use the longer shackles that Carrier supplies with those springs? IIRC, they're somewhere between 1/2" and 1" longer than stock, and that's a caster increase.[/QUOTE]
No I did not.
What I have decided to do is use the Moog K992 that installs in the lower king pin it looks stronger than the upper kit and more adjustable, best price was from Jegs @ 85.99 each free shipping., as I said earlier I'm at 3.1 on drivers side and 2.9 on pass. side and will set it at 4.2 drivers side and 4.5 on pass. side. The parts will hopefully be here by next Fri. 6/15 and can get them installed, will try using a digital angle gauge to try and get it set right
No I did not.
What I have decided to do is use the Moog K992 that installs in the lower king pin it looks stronger than the upper kit and more adjustable, best price was from Jegs @ 85.99 each free shipping., as I said earlier I'm at 3.1 on drivers side and 2.9 on pass. side and will set it at 4.2 drivers side and 4.5 on pass. side. The parts will hopefully be here by next Fri. 6/15 and can get them installed, will try using a digital angle gauge to try and get it set right
#25
Registered User
Personally, I think your front axle is messed up beyond repair. You better send it to me to take care of disposal!
#26
Registered User
Dana 60 camber shims, adjustable lower kingpin camber parts, Kingpin parts. - Pirate4x4.Com : 4x4 and Off-Road Forum
#27
Registered User
Actually there are tapered shim that change camber/ kingpin inclination.
Dana 60 camber shims, adjustable lower kingpin camber parts, Kingpin parts. - Pirate4x4.Com : 4x4 and Off-Road Forum
Dana 60 camber shims, adjustable lower kingpin camber parts, Kingpin parts. - Pirate4x4.Com : 4x4 and Off-Road Forum
EDIT: The last poster in that pirate thread had issues with the K992 part.
#28
Registered User
I need to rebuild my front end badly. However, just putting in the borgeson shaft and installing the red head steering g gear made the biggest difference. My tie rods are loose as hell but as my wife says “the steering is as smooth as butter”. It was 4 years ago since I installed the red head and it still is smooth.
The following users liked this post:
nonrev (06-09-2018)
#29
Registered User
Thread Starter
I think you will find that with most any product, and Pirate 4x4 trends more to people that rock crawl and trail ride their machines IMHO.
I do not believe the housing is bent and I have put many new parts in it. The only thing I have not replaced is the upper king pin itself, they looked good, no rough spots or galling. I used a autozone box because mine was leaking, a borgeson shaft, new pitman shaft, spicer greasable joints which I grease every 5000 miles, no play in the tie rod ends. I feel this thing should drive perfect and for the most part it does... BUT it does not track like it should hence the quest to try most anything to see if it will work. I'm not going to go wild with the caster, just about 1 degree more than the stock setting which is 3.2 left and 3.5 on the right, if that doesn't do it I will replace the housing. I truly appreciate all the thoughts and discussions this thread has had as I have definitely learned more about alignment issues on these front-ends than the typical "just set the toe and it will be fine" that most people think, again thank all of you for replying.
The following users liked this post:
mknittle (06-09-2018)
#30
Registered User
I feel this thing should drive perfect and for the most part it does... BUT it does not track like it should hence the quest to try most anything to see if it will work. I'm not going to go wild with the caster, just about 1 degree more than the stock setting which is 3.2 left and 3.5 on the right, if that doesn't do it I will replace the housing.
Chevy specs 6 degrees caster on identical Dana 60 outers. Hmmm....
